Why Choose EasyRapid Roll Up Doors?
Faster Workflow with High-Speed Operation
Operating speeds of up to 2.5m/s allow forklifts, pallet trucks, and personnel to move efficiently through access points, reducing waiting time and improving daily operations.
Better Energy Control
Fast opening and closing cycles minimise air exchange between work areas, helping reduce energy loss in air-conditioned factories, cold rooms, and refrigerated warehouses.
Less Downtime with Self-Repair Technology
Selected EasyRapid models automatically reset the curtain after accidental impact, reducing repair requirements and keeping operations running smoothly.
Built for Continuous Industrial Use
SIOEN PVC curtain material, robust guide rails, and servo motor technology provide reliable performance for demanding industrial environments.
Safer Automated Operation
Integrated safety sensors help detect obstacles during door movement, supporting safer operation for forklifts, vehicles, and personnel.
Flexible Solutions for Different Facilities
Available in multiple sizes, controls, curtain colours, and accessories to match different operational requirements.
EasyRapid Roll Up Door: 3 Variants
Every industrial facility has different operational requirements. EasyRapid is available in three configurations to suit different traffic volumes, temperature conditions, and performance needs.
Use the tabs below to compare each model and choose the most suitable solution for your facility.
Designed for general industrial applications, the Standard High-Speed Roll Up Door is suitable for warehouses, factories, logistics centres, and loading bays where reliable high-speed access is required.
It features a durable flame-retardant SIOEN PVC curtain, servo motor operation, and multiple activation options, making it an ideal solution for facilities with frequent daily traffic and standard environmental requirements.
Recommended for:
- Warehouses
- Manufacturing facilities
- Distribution centres
- Loading bays
- General industrial operations
| Specification | Details |
|---|---|
| Maximum Opening Size | 4,500mm (W) × 5,000mm (H) |
| Opening & Closing Speed | 0.8m/s – 1.2m/s (Adjustable) |
| Operating Temperature | 0°C to +40°C |
| Motor | Servo Motor, 0.75kW – 1.5kW, 50Hz, Absolute Encoder |
| Curtain Material | SIOEN PVC coated fabric, 0.8mm flame-retardant vinyl |
| Transparent Window | 1.2mm thick, available on each door |
| Guide Rail | Aluminium alloy, 120mm × 100mm × 2.5mm |
| Frame Material | SUS 304 stainless steel top roller motor cover |
| Safety | Photoelectric (PE) safety beam |
| Sealing | Two-row brush seal with black rubber bottom gasket |
| Wind Resistance | Wind bars integrated on each vinyl panel |
| Standard Control | Push button |
| Optional Accessories | Forklift sensor, motion sensor, pull cord, interlock, magnetic loop detector |
| Power Failure | Manual hand operation available |
Designed for temperature-controlled environments, the Insulated High-Speed Door features a 20mm insulated curtain that helps reduce heat transfer while maintaining stable internal temperatures.
Its integrated self-repair system automatically re-engages the curtain after accidental impact, reducing downtime and helping facilities maintain continuous operation.
Recommended for:
- Cold rooms
- Cold storage facilities
- Food processing plants
- Pharmaceutical facilities
- Temperature-controlled warehouses
| Specification | Details |
|---|---|
| Maximum Opening Size | 4,000mm (W) × 4,000mm (H) |
| Opening Speed | 0.5m/s – 1.2m/s |
| Closing Speed | 0.6m/s – 1.2m/s |
| Operating Temperature | -30°C to +70°C |
| Motor | Servo Motor, 0.75kW – 1.5kW, 50Hz, IP54 control panel |
| Curtain Material | 20mm double-layer insulated sandwich panel with fibre core |
| Curtain Thickness | 0.9mm |
| Curtain Colours | Red, Orange, Yellow, Green, Blue, Black, Grey, Transparent |
| Guide Rail | SUS 304 stainless steel top cover with aluminium vertical guide rail (120mm × 100mm × 2.5mm) |
| Door Frame | Stainless steel, aluminium, or galvanised steel |
| Safety | Photoelectric (PE) safety sensor |
| Standard Control | Schneider push button, remote control or motion sensor |
| Self-Repair Function | Yes, automatically re-engages after impact |
The Zip High-Speed Door is the highest-performance model in the EasyRapid range. Its zip-track sealing system provides excellent air sealing, wind resistance, and opening speeds of up to 2.5m/s.
Designed for high-cycle industrial environments, it automatically resets after accidental impact, helping minimise maintenance and maximise productivity.
Recommended for:
- High-traffic warehouses
- Distribution centres
- Automotive manufacturing
- Pharmaceutical production
- Cleanrooms
- Logistics hubs
| Specification | Details |
|---|---|
| Maximum Opening Size | 5,000mm (W) × 5,000mm (H) |
| Opening Speed | 0.8m/s – 2.5m/s (Adjustable) |
| Closing Speed | 0.6m/s – 0.8m/s |
| Operating Temperature | 0°C to +40°C |
| Motor | 0.75kW / 1.5kW Servo Motor with Servo Control Panel |
| Power Supply | 220V / 15A / Single Phase / 50Hz |
| Curtain Material | SIOEN PVC coated fabric, 0.9mm |
| Curtain Strength | 600N tear strength warp |
| Guide Rail | Mild steel powder-coated top cover |
| Wind Resistance | Wind Level 6 standard (Up to Level 8 on request) |
| Safety | Autonics photoelectric (PE) safety sensor |
| Sealing | Stainless steel vertical track with two-row rubber seal and black rubber bottom gasket |
| Control System | Advanced servo system, rated for over 300,000 operating cycles |
| Self-Repair Function | Yes, automatic zip-track re-engagement after impact |
| Optional Accessories | Forklift sensor, motion sensor, pull cord, interlock, magnetic loop detector, transparent window, safety light curtain |
Which Industrial Door Is Right for Your Facility?
Different industrial door systems are designed for different operational requirements. Choosing the right solution depends on traffic frequency, environmental control, automation needs, and workflow efficiency.
| Requirement | PVC Strip Curtain | PVC Swing Door | EasyRapid Roll Up Door |
|---|---|---|---|
| Traffic Frequency | Low | Medium | High |
| Opening Speed | ★ | ★★ | ★★★★★ |
| Temperature Control | ★★ | ★★★ | ★★★★★ |
| Automation | Optional | No | Yes |
| Energy Efficiency | Good | Better | Excellent |
| Hygiene Control | Good | Better | Excellent |
| Best For | General access | Internal traffic | High-frequency industrial operations |
If your facility experiences frequent forklift traffic, requires automated operation, or needs better temperature control, EasyRapid Roll Up Doors provide the most suitable long-term solution.
For lower-traffic areas, you may also consider our PVC Strip Curtains or PVC Swing Doors.
Why Choose EasyRapid Over Conventional Roller Shutters?
Although conventional roller shutters provide secure access, they are generally designed for occasional operation rather than high-frequency industrial traffic.
| EasyRapid Roll Up Door | Conventional Roller Shutter |
|---|---|
| Opens up to 2.5m/s | Slower opening and closing speed |
| Suitable for high-cycle operation | Better suited to occasional access |
| Self-repair option available | Manual repair required after impact |
| Better environmental sealing | Greater air exchange |
| Supports automated operation | Basic motor operation |
| Lower long-term downtime | Higher maintenance in busy facilities |
For warehouses, manufacturing plants, and logistics centres with continuous daily operations, a high-speed roll up door can improve productivity while reducing operational interruptions.
For more information about different industrial door solutions, explore our complete range of high-speed doors in Malaysia.
Industries We Serve
EasyRapid Roll Up Doors are designed for various industrial environments requiring fast access, improved workflow, and better environmental control.
Warehouses & Distribution Centres
Supports continuous forklift movement while reducing waiting time and maintaining efficient workflow between operational zones.
Manufacturing Facilities
Provides reliable high-speed access between production areas while helping reduce dust and improve operational efficiency.
Cold Storage & Cold Chain
Helps minimise cold air loss during frequent access, making it suitable for refrigerated warehouses, cold rooms, and temperature-controlled logistics.
Food Processing & Pharmaceutical Facilities
Supports hygiene-sensitive operations by reducing air exchange and helping maintain controlled environments.
Loading Bays
Improves loading and unloading efficiency while reducing exposure to wind, dust, and external weather conditions.
Frequently Asked Questions (FAQs)
What is a high-speed roll up door?
A high-speed roll up door is an industrial door designed to open and close quickly for areas with frequent traffic movement. It is commonly used in warehouses, factories, logistics centres, and loading bays to improve workflow efficiency, reduce waiting time, and help control dust, temperature, and air exchange.
What is a self-repair high-speed door?
A self-repair high-speed door is an advanced industrial door designed to recover automatically after certain accidental impacts. When the curtain is displaced by a forklift or vehicle impact, the system can reposition the curtain back into the guide tracks, helping reduce downtime and maintenance requirements.
How does a self-repair high-speed door work?
A self-repair high-speed door uses a flexible curtain and specially designed guide system that allows the curtain to release during an impact and automatically reset during normal operation. This helps restore door function quickly without requiring immediate manual repair after minor collisions.
What is the difference between a standard high-speed door and a self-repair door?
A standard high-speed door is suitable for general industrial access where impact risks are low. A self-repair high-speed door includes an impact recovery feature, making it more suitable for busy environments with frequent forklift, pallet truck, or vehicle movement.
What are the benefits of a self-repair high-speed door?
A self-repair high-speed door helps reduce operational downtime, minimise repair needs, and improve productivity in high-traffic areas. It is especially beneficial for warehouses, manufacturing facilities, and logistics operations where accidental door impacts can interrupt daily workflows.
Where are high-speed roll up doors used?
High-speed roll up doors are commonly installed in warehouses, manufacturing plants, distribution centres, loading bays, cold storage facilities, food processing areas, and pharmaceutical environments. They are suitable for applications requiring fast access, better environmental control, and frequent opening cycles.
Are high-speed doors suitable for forklift traffic?
Yes. High-speed doors are designed for facilities with regular forklift and vehicle movement. Their fast opening and closing speeds help reduce waiting time, improve traffic flow, and maintain safer movement between different operational areas.
Can high-speed roll up doors improve energy efficiency?
Yes. High-speed roll up doors help reduce energy loss by minimising the time an opening remains exposed. Faster opening and closing cycles reduce air exchange, making them suitable for temperature-controlled environments such as cold rooms, refrigerated warehouses, and air-conditioned production areas.
How much does a high-speed roll up door cost in Malaysia?
The cost of a high-speed roll up door depends on factors such as door size, selected model, opening speed, curtain material, automation options, safety features, and installation requirements. A customised quotation is recommended to ensure the door meets your facility’s operational needs.
How do I choose the right high-speed door for my facility?
Choosing the right high-speed door depends on your traffic volume, operating environment, temperature requirements, safety needs, and maintenance expectations. Standard models are suitable for general applications, while self-repair models are recommended for areas with frequent forklift or vehicle movement.
Looking for a Rapid Roll Up Door in Malaysia?
Whether you’re upgrading an existing industrial door or planning a new facility, our team can recommend the most suitable EasyRapid solution based on your operational requirements, traffic volume, and installation environment.
